Excavators

• Some others have a knuckle boom which can also move left and right in line with the machine.
• The other option is a hinge at the base of the boom allowing it to hydraulically pivot up to 180° independent to the house, however this is generally available only to compact excavators.
Attached to the end of the boom is the stick (or dipper arm). The stick provides the digging force needed to pull the bucket through the ground. The stick length is optional depending whether reach (longer stick) or break-out power (shorter stick) is required.
On the end of the stick is usually a bucket. A wide, large capacity (Mud) bucket with a straight cutting edge is used for cleanup and levelling or where the material to be dug is soft, and teeth are not required. A general purpose (GP) bucket is generally smaller, stronger, and has hardened side cutters and teeth used to break through hard ground and rocks. Buckets have numerous shapes and sizes for various applications. There are also many other attachments which are available to be attached to the excavator for boring, ripping, crushing, cutting, lifting, etc.
