Tank Drawing

• Configuration of Tanks
To the above can be added unit communication systems and electronic anti-tank countermeasures, crew ergonomic and survival systems (including flame suppression), and provision for technological upgrading. Most tank designs have rarely survived their entire service life without some upgrading or modernisation, particularly during wartime, including some that changed almost beyond recognition, such as the latest Israeli Magach versions.
The characteristics of a tank are determined by the performance criteria required for the tank. The obstacles that must be traversed affect the vehicles front and rear profiles. The terrain that is expected to be traversed determines the track ground pressure that may be allowed to be exerted for that particular terrain.
